ASUSTOR Lockerstor 8 AS6508T

ASUSTOR LOCKERSTOR 8 AS6508T 8-bay NAS

#AS6508T

Intel Denverton-based Atom C3538 Quad-Core CPU
8GB DDR4-2133 SO-DIMM – 30% faster than DDR3
Dual Intel 10-Gigabit Ethernet ports – Supports up to 20 Gbps under Link Aggregation
Dual Realtek 2.5-Gigabit Ethernet ports – Supports up to 5 Gbps under Link Aggregation
Supports 8x 3½” SATA hard drives
Dual M.2 NVMe SSD ports for fast caching
Supports an extra 128 TB with the AS6004U
Thumbscrews for easy M.2 SSD installation
Supports Wake on LAN and Wake on WAN
Efficient cooling design
Best in class three year warranty

Guarantee safe & secure checkout

Free Shipping & Returns : On all order

Categories : asustor, Power User to Business

Description
Reviews (0)

Description

Specifications:

Specifications
CPU
CPU Model	Intel ATOM C3538
CPU Architecture	x64 64-bit
CPU Frequency	Quad Core 2.1GHz
Memory
Memory	8GB SO-DIMM DDR4
Memory Module Pre-installed	8GB (1 x 8GB)
Total Memory Slots	2
Memory Expandable up to	32GB (2 x 16GB) Support mixed capacity YouTube
Flash Memory	4GB eMMC
Storage
HDD	8 x SATA3 6Gb/s; 3.5″/2.5″ HDD/SSD¹
M.2 Drive Slots	2x M.2 PCIe (NVMe) or SATA SSD for SSD Caching *Support M.2 2280, 2260 and 2242.
Maximum Internal Raw Capacity	128 TB (16 TB HDD X 8, Capacity may vary by RAID types)
Maximum Drive Bays with Expansion Unit	16
Maximum Raw Capacity with Expansion Units	256 TB (16 TB HDD X 16, Capacity may vary by RAID types)
External Ports
Expansion	USB 3.2 Gen 1 x 2
Network	10 Gigabit Ethernet x 2; 2.5 Gigabit Ethernet x 2
HDMI Output	N/A
Others
System Fan	120mm x 2
LCD Panel	Yes
Power Supply Unit / Adapter	250W x1
Input Power Voltage	100V to 240V AC
Certification	FCC, CE, VCCI, BSMI, C-TICK
Operation
Power Consumption	66.9W (Operation); 37.2W (Disk Hibernation)²
Noise Level	22dB (HDD idle)
Operation Temperature	0°C~40°C (32°F~104°F)
Humidity	5% to 95% RH
Size and Weight
Size	215.5(H) x 293(W) x 230(D) mm
Weight	6.2 (kg) / 13.67 (lb)
Package Contents
Package Contents	Lockerstor 8 (AS6508T) Unit Quick Installation Guide AC Power Cord x1 RJ-45 LAN Cable (Cat 5e) x2 10GBE LAN Cable(Cat 6a) x2 Flat Head Screw (for 3.5″ HDD) x32 Flat Head Screw (for 2.5″ HDD) x32 M.2 thumbscrews x2

¹ Hard disks not included.
² Test HDD: WD Red 3 TB HDD
³ USB Wi-Fi dongle not included.
⁴ You must first enable real time transcoding for these files in order to play them.
⁵ Metadata (e.g. title) may not be able to displayed in iTunes.

Pricing Notes:

Pricing and product availability subject to change without notice.
