ASUSTOR Lockerstor 16R Pro AS7116RDX ,

ASUSTOR LOCKERSTOR 16R Pro AS7116RDX 16-bay NAS

#AS7116RDX

Intel Xeon 9th generation Quad-Core CPU
Server-grade ECC memory: 8 GB ECC DDR4-2666 (Max 128GB, 32GB x 4)
2U chassis design, 12 SATA drive bays
Dual M.2 NVMe SSD ports for fast caching
Complete iSCSI/IP-SAN and NFS support. VMware, Citrix and Hyper-V ready.
Supports Virtualization and Docker apps
PCIe slots for 10/25/40/50 Gigabit Ethernet cards as well as SAS cards.
Windows ACL support combined with Windows AD infrastructure enhances management efficiency for business applications

Guarantee safe & secure checkout

Free Shipping & Returns : On all order

Category : asustor

Description
Reviews (0)

Description

Specifications:

AS7116RDX Hardware Specifications
CPU	CPU Model	Intel Xeon E-2224
	CPU Architecture	x64 64-bit
	CPU Frequency	Quad Core 3.4GHz up to 4.6GHz
Memory	Memory	8GB DDR4 ECC UDIMM
	Memory Module Pre-installed	8GB (1 x 8GB)
	Total Memory Slots	4
	Memory Expandable up to	128GB (4 x 32GB) Support mixed capacity
	Flash Memory	8GB USB DOM
Storage	HDD	16 x SATA3 6Gb/s; 3.5″/2.5″ HDD/SSD
	M.2 Drive Slots (SSD Cache)	2x M.2 PCIe (NVMe) / SATA *M.2 22110, 2280, 2260, 2242.
	Maximum Internal Raw Capacity	288 TB (18 TB HDD X 16, Capacity may vary by RAID types)
	Maximum Drive Bays with Expansion Unit	24
	Maximum Raw Capacity with Expansion Units	432 TB (18 TB HDD X 24, Capacity may vary by RAID & M.2 types)
External Ports	Expansion	USB 3.2 Gen 2 x 4 Type-A ; USB 3.2 Gen 2 x 2 Type-C
	Network	Gigabit Ethernet x 4
	PCIe Expansion Slots	PCIe Expansion Slots: 2 x Gen3 x4 slots (x4 link) ; 1 x Gen3 x8 slots (x8 link) for optional 10/25/40/50 GbE card and SAS card
	HDMI Output	N/A
Others	System Fan	60mm x 3
	Power Supply Unit / Adapter	550W x2
	Input Power Voltage	100V to 240V AC
	Redundant power supply
	Service LED Indicator
	Certification	FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC
Operation	Power Consumption	121.7W (Operation); 51.5W (Disk Hibernation) 7.55 W (Sleep Mode);
	Noise Level	N/A
	Operation Temperature	0°C~40°C (32°F~104°F)
	Humidity	5% to 95% RH
Size and Weight	Size	132(H) x 439(W) x 535(D) mm
	Weight	15.3 (kg) / 39.6(lb)
