ASUSTOR Lockerstor 6 AS6706T ,..

ASUSTOR LOCKERSTOR 6 Gen2 AS6702T 6-bay NAS

#AS6706T

Quad-Core 10 nm Intel Celeron N5105 CPU – 31% more performance over Gemini Lake
Superfast 2.5-Gigabit Ethernet ports
Flexible PCIe slot for M.2 SSDs
Supports PCIe 3.0 SSDs for up to twice the performance of PCIe 2.0.
Uses DDR4-2933 with 40% more performance
USB 3.2 Gen2 ports – 10Gbps speed
Enjoy, download, upload and stream content with 4K transcoding
Increased ventilation for SSDs
Supports Wake on LAN and Wake on WAN

Ask a Question

Guarantee safe & secure checkout

Free Shipping & Returns : On all order

Categories : asustor, Power User to Business

Description
Reviews (0)

Description

Specifications:

Hardware Specifications
CPU	CPU Model	Intel Celeron N5105
	CPU Architecture	x64 64-bit
	CPU Frequency	Quad-Core 2.0GHz (burst up 2.90 GHz)
Memory	Memory	4GB SO-DIMM DDR4 Compatibility
	Memory Module Pre-installed	4GB (1 x 4GB)
	Total Memory Slots	2
	Memory Expandable up to	16GB (2x 8GB) Installation Guide Support mixed capacity
	Flash Memory	8GB eMMC
Storage	Drive Bays	6
	M.2 Drive Slots	4 Installation Guide
	Compatible Drive Type	3.5″ SATA HDD 2.5″ SATA HDD 2.5″ SATA SSD M.2 2280 NVMe
	Maximum Drive Bays with Expansion Unit	14
External Ports	Expansion	2x USB 3.2 Gen 2×1
	Network	2x 2.5 Gigabit Ethernet (2.5G/1G/100M)
	HDMI Output	1x HDMI 2.0b
Others	System Fan	1x 120mm
	Infrared Receiver	Yes
	Power Supply Unit / Adapter	250W x1
	Input Power Voltage	100V to 240V AC
	Certification	FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC, UKCA
Operation	Power Consumption	48.5 W (Operation); 27.7 W (Disk Hibernation); 0.81 W (Sleep Mode)
	Noise Level	18.1dB (HDD idle)
	Operation Temperature	0°C~40°C (32°F~104°F)
	Humidity	5% to 95% RH
Size and Weight	Size	185.5 (H) x 233 (W) x 230 (D) mm
	Weight	4.4 kg / 9.7 lb

Pricing Notes:

Pricing and product availability subject to change without notice.

Reviews

There are no reviews yet.

Be the first to review “ASUSTOR Lockerstor 6 AS6706T ,..”

Quick Comparison

ASUSTOR Lockerstor 6 AS6706T ,.. remove ASUSTOR Lockerstor 16R Pro AS7116RDX , remove LOCKERSTOR 10 Gen3 (AS6810T) | Ryzen up to the challenge! remove ASUSTOR Lockerstor 12R Pro AS7112RDX remove Asustor LOCKERSTOR 8 Gen3 (AS6808T) | Ryzen up to the challenge! remove ASUSTOR Lockerstor 10 AS6510T .,, remove

Name ASUSTOR Lockerstor 6 AS6706T ,.. remove ASUSTOR Lockerstor 16R Pro AS7116RDX , remove LOCKERSTOR 10 Gen3 (AS6810T) | Ryzen up to the challenge! remove ASUSTOR Lockerstor 12R Pro AS7112RDX remove Asustor LOCKERSTOR 8 Gen3 (AS6808T) | Ryzen up to the challenge! remove ASUSTOR Lockerstor 10 AS6510T .,, remove


SKU

Rating

Rated 0 out of 5

Price

Stock

Available on backorder

Weight N/A N/A N/A N/A N/A N/A

Dimensions N/A N/A N/A N/A N/A N/A

Additional information

Description

ASUSTOR LOCKERSTOR 6 Gen2 AS6702T 6-bay NAS

#AS6706T

Quad-Core 10 nm Intel Celeron N5105 CPU - 31% more performance over Gemini Lake
Superfast 2.5-Gigabit Ethernet ports
Flexible PCIe slot for M.2 SSDs
Supports PCIe 3.0 SSDs for up to twice the performance of PCIe 2.0.
Uses DDR4-2933 with 40% more performance
USB 3.2 Gen2 ports – 10Gbps speed
Enjoy, download, upload and stream content with 4K transcoding
Increased ventilation for SSDs
Supports Wake on LAN and Wake on WAN

ASUSTOR LOCKERSTOR 16R Pro AS7116RDX 16-bay NAS

#AS7116RDX

Intel Xeon 9th generation Quad-Core CPU
Server-grade ECC memory: 8 GB ECC DDR4-2666 (Max 128GB, 32GB x 4)
2U chassis design, 12 SATA drive bays
Dual M.2 NVMe SSD ports for fast caching
Complete iSCSI/IP-SAN and NFS support. VMware, Citrix and Hyper-V ready.
Supports Virtualization and Docker apps
PCIe slots for 10/25/40/50 Gigabit Ethernet cards as well as SAS cards.
Windows ACL support combined with Windows AD infrastructure enhances management efficiency for business applications

Specification	Details
Model Options	Lockerstor 10 Gen 3 (AS6810T)
Processor	AMD Ryzen V3000 (Embedded), Quad-Core, 2.3 GHz base clock, 3.8 GHz turbo clock
Processor Architecture	Zen 3+ (Rembrandt), 6 nm process (Socket FP7)4
Memory	16GB DDR5 ECC (expandable up to 64GB)
Memory Speed	DDR5-4800 MT/s, Dual-channel, ECC supported
PCIe Lanes	20 lanes, PCIe Gen 4
Drive Bays	4 x 3.5″/2.5″ SATA HDD/SSD
M.2 NVMe Slots	4 x M.2 NVMe Gen 4 (PCIe Gen 4 x1 each slot)
Network Ports	2 x 10GbE RJ45 (Copper),,,,,, 2 x 5GbE RJ45 (Copper)
USB Ports	2 x USB4 (40 Gbps, Thunderbolt ), 3 x USB 3.2 Gen 2 Type-A (10 Gbps)
Cooling	1 x 120mm rear fan, additional copper finned heat pipe for CPU and M.2 slot cooling
Display Panel	Front-mounted LCD with configuration and system information
Power Supply	90W external adapter
Power Consumption	Idle: ~30-32W, Moderate Load: ~38-50W
Max Supported Drive Capacity	Up to 24TB per bay for SATA HDDs (depends on compatibility list)
RAID Levels Supported	Single, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10
File Systems	Internal: EXT4, Btrfs; External: FAT32, NTFS, EXT3, EXT4, HFS+, exFAT
Software	ADM 5 (Asustor Data Manager)
Virtualization Support	Supports Docker, Virtual Machines, and Container Station
Other Features	SMB Multichannel,,,,,, Snapshot Center,,,,,, DataSync Center,,,, Cloud Backup Center, ,,,,MyArchive cold storage
Warranty	3 years
Dimensions	185.5(H) x 170(W) x 230(D) mm
Weight	3.2 kg / 7.06 lbs

ASUSTOR LOCKERSTOR 12R Pro AS7112RDX 12-bay NAS

#AS7112RDX

Intel Xeon 9th generation Quad-Core CPU
Server-grade ECC memory: 8 GB ECC DDR4-2666 (Max 128GB, 32GB x 4)
2U chassis design, 12 SATA drive bays
Dual M.2 NVMe SSD ports for fast caching
Complete iSCSI/IP-SAN and NFS support. VMware, Citrix and Hyper-V ready.
Supports Virtualization and Docker apps
PCIe slots for 10/25/40/50 Gigabit Ethernet cards as well as SAS cards.
Windows ACL support combined with Windows AD infrastructure enhances management efficiency for business applications

Quad-Core AMD Ryzen Embedded V3C14 CPU @ 2.3 GHz - 3.8 GHz Turbo
16GB of server-grade DDR5-4800 ECC memory (Max 64GB)
Quad M.2 slots for NVMe SSDs – Doubled Performance with PCIe 4.0
2x USB4 ports at 40 Gbps
3x USB 3.2 Gen 2 Type-A at 10 Gbps
2x 10-Gigabit Ethernet
2x 5-Gigabit Ethernet
Supports Wake on LAN and Wake on WAN (5 GbE)

ASUSTOR LOCKERSTOR 10 AS6510T 10-bay NAS

#AS6510T

Intel Denverton-based Atom C3538 Quad-Core CPU
8GB DDR4-2133 SO-DIMM - 30% faster than DDR3
Dual Intel 10-Gigabit Ethernet ports - Supports up to 20 Gbps under Link Aggregation
Dual Realtek 2.5-Gigabit Ethernet ports - Supports up to 5 Gbps under Link Aggregation
Supports 8x 3½" SATA hard drives
Dual M.2 NVMe SSD ports for fast caching
Supports an extra 128 TB with the AS6004U
Thumbscrews for easy M.2 SSD installation
Supports Wake on LAN and Wake on WAN
Efficient cooling design
Best in class three year warranty
