XstreamCORE 8100-TS0 Dual-Port 10Gb Ethernet to 4-port 12Gb SAS intelligent Bridge (supports tape storage media only)
10Gb Ethernet to 12Gb/s SAS intelligent Bridge. Easily connect and share SAS Tape drives via iSCSI Ethernet.
- This product SKU supports tape devices ONLY.
- Two 10Gb/s Ethernet SFP+ ports for iSCSI host connections
- Optical SFP+ module(s) included
- Single x4 12Gb/s miniSAS HD SFF-8644 port; auto negotiates to 6Gb/s
- Support for up to 4 SAS Tape drives per bridge
- Supports LTO 5 (or) later
- Up to 2GB/s sustained transfer rate
- Operating system independent – iSCSI Initiator required.
- Web-based GUI for device configuration and management
- Features LEDs for port status, power supply, and bridge status
- Supports SAS Tape Drives and Libraries
- Battery-free design
- RoHS compliant
- 3-year standard product warranty (optional 5-year total warranty and advanced replacement available)
All finished good XCET 8100T SKUs include: ATTO XstreamCORE 8100T intelligent Bridge, SFP module(s), power adapter, and cable. 8100T is ISV agnostic and supports all leading backup software application packages.
Guarantee safe & secure checkout
On all order
Description
ATTO XstreamCORE ET 8100T Bridge adds Ethernet connectivity to SAS Tape storage to provide remote connectivity, sharing and common services with minimal added latency.
Extend SAS Tape Drive Connectivity Beyond the Rack
Over the last decade, IT complexity has grown exponentially as data growth continues to strain critical infrastructure resources. The development of cloud platforms, big data, data analytics, and distributed computing has led to an increase in the number and scale of data center deployments. Extending connectivity to SAS tape beyond the rack has always been challenging as it is limited by the SAS interface. Data protection and backup has moved to a decentralized model which has resulted in the creation of silos across multiple locations. This could be within the same data center, across a campus or even at edge computing locations. ATTO XstreamCORE ET 8100T helps bridge this gap by elevating common control for backup and archive workflows across an Ethernet network. Additionally, File and Object Storage are growing at a much faster rate than block storage. Ethernet is better suited to handling this unstructured data while providing a lower cost of implementation compared to Fibre Channel tape connectivity.
Power Backup & Archive with Unmatched Simplicity and Efficiency
ATTO XstreamCORE ET 8100T is a simple, purpose-built, and cost-effective intelligent bridging solution allowing businesses and enterprises to deploy secured and shared access to tape storage over a 10Gb Ethernet iSCSI network. Powered by a custom chipset and ATTO engineered software, 8100T sets a new standard for tape library connectivity. 8100T allows up to eight iSCSI host logins to connect up to four SAS tape drives with an aggregate throughput of up to 2000 MBps, maximizing drive shareability.
XstreamCORE 8100T features patented ATTO SpeedWrite technology to ensure that tape drives fully utilize the available bandwidth. The bridge is equipped with a dedicated management interface that uses a secure CLI or a user-friendly web-based tool for ease of setup and diagnostics. XstreamCORE 8100T offers a secure digital pathway to integrate data resilience for protecting sensitive business applications and customer data, ensuring workplace collaboration and productivity, and fueling growth.
ATTO Data Acceleration
ATTO Distributed Software Architecture (ADSA) is the heart of the XstreamCORE 8100T. A self-optimizing real-time operating system designed specifically for embedded hardware, ADSA acts as a translator of one protocol to another and integrates advanced protocol, error handling and application requirements into an existing infrastructure. The on- board data acceleration technology features multiple parallel I/O engines with end-end I/O processing and intelligent management of hardware buffer allocation. The ATTO Distributed Software System provides a cooperative, multi-tasking environment complete with a core set of services for our product applications. ADSA architecture is designed to maximize workflow productivity and enhance control over backup and archive platforms.
Designed for Sustainability
Sharing libraries typically requires costly Fibre Channel infrastructure, or the use of servers in front of the tape libraries to enable Ethernet connectivity. Servers require more power and cooling, expensive licenses, maintenance, and take up rack space. ATTO XstreamCORE ET 8100T intelligent bridges provide a simple, low-maintenance connectivity option. Each bridge consumes less than 30 Watts and can easily be embedded in a tape library using standard connections, or a small external chassis can be installed in a standard data center 1U rack. This results in lower power budget requirements for the infrastructure design.
Tech data
Connectivity
- Ethernet Specifications 2x 10GbE SFP+ (or) RJ45 SFP ports, IPv4/IPv6. SCSI Network Protocol Support, Multi-Initiator Access
- Wkładki optyczne RJ45 INCLUDES
- SAS Specifications: Single x4 12Gb/s mini-SAS HD connector, Auto negotiates 12Gb/6Gb, SAS-2, SAS-3, SAS TLR
- Tape Drive Specifications: Supports up to four SAS
- Tape drives per bridge: Supports LTO 7,8,9
- Management: Dedicated RJ45 1GbE management port, CLI over SSH, File
- Transfer over SFTP, Simplified configuration and diagnostics capabilities via CLI, User friendly web-based GUI for easy setup, configuration, and management., Core dump error and event log analysis, Built-in temperature monitoring, Support for leading ISVs
- Form Factor: Standalone
- Product Dimensions: 1.2” x 4.0” x 9.4” (30.5mm x 103.5mm x 240mm)
- Weight 2.05 pounds (with SFPs) 2.00 pounds (without SFPs)
- Operating System Support OS independent – iSCSI initiator required
- Power and Airflow: Typical Power 23W, Max Power 25W, 100% duty cycle at 35°C, 200 LFM airflow – Ambient air not to exceed 40°C
- Operating Environment: Temperature 5°C – 40°C at 10,000 ft, Humidity 10% – 90%, non -condensing
- Agency Approvals & Compliance: EN62368, UL 62368 EMI/EMC, FCC Part 15 Class A, EN55032 class A, EN55024, ICES-003 Class A, AS/NZS , VCCI, RoHS 3 2016/863/EU
- Warranty: Three year standard product warranty
