| Description |
- Dual 25 Gb/s Thunderbolt 3/4 Ports
- DisplayPort & Device Daisy-Chain Support
- macOS and Windows Supported
- Kensington Security Slot
- SFP28 Optical Modules Included
|
- Create Shareable NVMe Storage Pools
- Supports 16 x2 Drives
- PCIe 4.0 x16 Host Connection
- SlimSAS Connectors
- RoHS Compliant
|
- Network Interface with SFP28 Connectors
- Supports Line Speeds up to 25 Gb/s
- Use Across Data Center from Core to Edge
- ATTO 360 Tuning, Monitoring & Analytics
|
- 2 x 40 Gb/s Thunderbolt 3 Ports
- 2 x 16 Gb/s Fiber Channel with Optics
- Thunderbolt Certified for Windows & Mac
- Advanced Data Streaming Technology
- Real-Time Streaming of Full HD & 4K
- Low Profile Form Factor
- Kensington Security Slot
- Locking Power Supply
|
- 4 x 25G SFP28 Slots
- 2 x Thunderbolt 5 Ports
- Advanced Data Streaming Technology
- Includes SFP28 Transceiver Modules
- Low-Profile Design
- Works with Windows, macOS & Linux
|
-
ATTO FastFrame N412 (2 x Transceiver Included) – Technical Specifications
| Product SKU |
FFRM-N412-000 |
| Form Factor |
Low profile PCIe plug-in card |
| PCIe Interface |
PCIe 4.0 x16 (mechanical and electrical) |
| Number of Ports |
2 (Dual-port) |
| Connector Type |
QSFP28 |
| Included Modules |
QSFP28 module(s) included |
| Supported Speeds |
10/25/40/50/100GbE |
| Maximum Throughput |
100Gb/s per port |
| Minimum Latency |
Approximately 1µs |
| Operating Systems Support |
macOS, Windows, Windows Server, Linux |
| Network/Transport Protocol |
TCP/IP, UDP/IP |
| Advanced Features |
MSI-X, MSI, DCA, RoCE, NVGRE, PCI-SIG SR-IOV-ready, Erasure Coding offload, RDMA support, end-to-end encryption, RSS, TSS, ADS |
| Hardware Offloads |
TCP/UDP/IP stateless offloads, NVMe over Fabrics target offload (100Gb only) |
| IEEE Standards |
IEEE 802.3ad (Link aggregation), IEEE 802.1qbb (Priority flow control) |
| Operating Temperature |
0-55°C |
| Maximum Junction Temperature |
110°C |
| Required Airflow |
225 LFM DAC, 420 LFM optics |
| Operating Humidity |
10-90% non-condensing |
| Storage Temperature |
-40°C to 70°C |
| Storage Humidity |
5-95% non-condensing |
| Agency Approvals |
FCC Part 15 Subpart B, Class A; EN55022: 2010, Class A; EN55024: 2010 |
| Compliance |
EN60950-1, EN60825-1, EN60825-2, RoHS, TAA Compliant |
| Warranty |
3-year standard product warranty |
| Package Contents |
ATTO FastFrame Ethernet SmartNIC adapter, low profile bracket, QSFP28 module(s) |
| Recommended Applications |
AI workloads, GPU computing, core Ethernet infrastructure, video post-production, digital imaging, data analytics, hyper-converged servers |
|
